Metal Coil Seat Pad- Composite EVA Foam
Resin
|
|
|
|
|
Safer& more economical
coil stroage solution
|
|
|
|
|
|
Economical
|
l Eliminate commercial losses
resulted from transportation and storage.
l Fast and easy installation &
extreme long lifetime.
|
|
|
|
|
|
|
|
Safety
|
l Safety guarantee for personnel.
l Non-toxic. Eight heavy metals none
detected.
|
|
|
|
|
|
|
|
High-performance
|
l Impact resistant, weather
resistance, oil resistant difficult to crack
l Fully cladded to steel coil
curvature, evenly stressed for the contact surface.
|
|
|
|
|
|
|
|
High-loading
|
l Highest load bearing capacity
reaches 100ton/30cm²
l Carries up to 3 layers of steel
coils.
|
|
|
|
|
|
|
|
Eco-material
|
l Environment friendly recyclable
material.
l No generation of dioxin after
burning.
|
|
|
|
|
|
|
|
|
V Type (2pcs per coil)
|
|
|
|
|
|
|
|
|
Model
|
Angle
|
Weight (kg)
|
Size
(mm)
|
|
V-750
|
15°
|
5
|
750x153x155
|
|
V-900
|
15°
|
7
|
900x190x155
|
|
V-750H
|
18°
|
5.2
|
750x153x175
|
|
V-900H
|
18°
|
7.2
|
900x190x175
|
|
|
|
|
|
|
VL Type
|
|
|
|
|
|
|
|
|
Model
|
Angle
|
Weight (kg)
|
Size
(mm)
|
|
VL-650
|
15°
|
12
|
650x900x125
|
|
VL-750
|
15°
|
14
|
750x900x125
|
|
VL-900
|
15°
|
20
|
900x900x155
|
|
VL-650H
|
18°
|
12.4
|
650x900x148
|
|
VL-750H
|
18°
|
14.4
|
750x900x148
|
|
VL-900H
|
18°
|
20.4
|
900x900x175
|
|
|
|
|
|
|
DL Type
|
|
|
|
|
|
|
|
|
Model
|
Angle
|
Weight (kg)
|
Size
(mm)
|
|
DL-550
|
18°
|
13
|
550x900x107
|
|
DL-650
|
18°
|
14
|
650x900x107
|
|
|
|
|
|
|
Customized Product
|
|
We offer customized product to fit in
the iron shelf or iron rail.
|
|
|
V type with groove
|
|
|
V-880
880Lx153Wx182H
|
|
|
|
|
Long type
|
|
|
L-900
90h
x150W x150H x900L
|
|
|
|
|
|
Block type
|
|
|
V-405
405L
x165W x160H
|
|
|
|
|
|
